TCS34725 Renk Sensör Modülü Color Sensor RGB Recognition

     TCS3472 devices available in red, green and blue (RGB) and digital Mingguang induction return value. Color sensitive photodiode integrated sheet cutting and localized infrared light blocking filter, minimizing the infrared spectral components of the incident light, so that more accurate color management. High sensitivity, wide dynamic range and an infrared light blocking filter makes TCS3472 become ideal lighting conditions change and through color sensitive element attenuating materials under conditions of solution.

Specification:

     Red, Green, Blue (RGB), and White Light Sensing with IR Blocking Filter
     Programmable Analog Gain and Integration Time
     3,800,000:1 Dynamic Range
     Working voltage: 3.3~5V
     Detection distance: 3 ~ 10mm
     Communication method: IIC
     Very High Sensitivity : Ideally Suited for Operation Behind Dark Glass
     Maskable Interrupt
     Programmable Upper and Lower Thresholds with Persistence Filter
     Power Management
     Low Power : 2.5-uA Sleep State
     65-uA Wait State with Programmable Wait State Time from 2.4 ms to > 7 Seconds
     I2C Fast Mode Compatible Interface
     Data Rates up to 400 kbit/s
     Input Voltage Levels Compatible with VDD or 1.8 V Bus
     Register Set and Pin Compatible with the TCS3x71 Series
     Small 2 mm*2.4 mm Dual Flat No-Lead (FN)


Product Pin Definitions:

    VIN power supply positive
    GND power supply negative
    3V3 3.3V output
    SCL clock signal
    SDA data signal
    INT interrupt output, active low
    The LED controls the LED light near the sensor. When the high level signal is on or off, the LED light is on, and the low level signal LED is off.

Paket İçeriği :

    1 Adet TCS34725 Renk Sensör Modülü
